Construction

By offering tailored shipping and logistics solutions for construction equipment, whether as built-up or knocked-down units, we can meet the complex needs of our customers.

High and heavy processing in Baltimore

General economic development, and more specifically investments in residential, non-residential and infrastructure projects, both private and public, are key drivers in the demand for construction equipment. In the coming years, global construction equipment sales are expected to soften but remain relatively close to the historically high volumes reached in 2018.

We accommodate a wide variety of construction equipment – from cranes, excavators and pavers, to bulldozers and dump trucks. Combining our inland logistics services with reliable and stable ocean transportation, provides the flexibility you need to meet your customers’ expectations for on-time delivery.

Do you need inland logistics services?

We offer a variety of processing and technical services at our port and inland processing centres, as well as at your factories and shipping floors. We can store, inspect, repair, assemble, customise and transport machines to meet the specific needs of your end customers.

Dubai EPC

Do you need ocean transportation services?

Our global network reach, local knowledge, expertise in ports worldwide, and high frequency liner services provides you with safe and smart ocean transportation at the lowest total transport cost.

We transport all types of rolling construction equipment by loading and discharging via a stern ramp onto the vessel. This is a secure and efficient process that ensures safe handling regardless of weather conditions.

Our service is not only limited to rolling units. Our experienced staff around the world can handle your non-rolling units on innovative equipment solutions that minimise lifting and ensure a smooth voyage to the desired destination.


6.1 metres high
12 metres wide
400 tonnes in weight

We encourage shippers to send non-rolling products ‘as is’ without additional packaging. This enables our cargo handling specialists to clearly see the cargo and to ensure proper handling and stowage, while also reducing your packing costs.

Parsifal

Variety of cargo handling equipment

Our technical specialists are on hand every step of the way to oversee and ensure proper handling and stowage and make sure the right equipment solutions are deployed for a safe voyage. See our range of cargo handling equipment for construction products.

Equipment solutions for construction

Equipment details

< 220 MT

Cargo max weight

6-18 m

Cargo max length

8-16 m

Equipment length

3 m

Equipment width

1.1 m

Equipment height

Samson heavy-lift trailer

One of our original designs, ideal for breakbulk up to 220 tonnes. They are available in 8, 10 and 16 m versions, ensuring there’s always a perfect fit for your needs. Cargo types include: transformers, generators and turbine rotors.

Equipment details

< 140 MT

Cargo max weight

< 28 m

Cargo max length

20’-80’ feet (6-24 m)

Equipment length

2.5 m

Equipment width

0.44-1.1 m

Equipment height

Roll trailers

The workhorse of our equipment fleet, roll trailers have been developed for cargo up to 140 tonnes. Roll trailers are simply towed on and off the vessel. Cargo types: all kinds of breakbulk from machine tools to crane counterweights. We also offer specialised railed roll trailers for rail cars and extra low profile roll trailers for particularly tall cargo.

Equipment details

< 400 MT

Cargo max weight

< 50 m

Cargo max length

approx 1.55 m

Equipment height

Blocks and Beams

Jack-up trailers with blocks and beams are used to handle RoRo cargo of up to 400 tonnes and are configured to suit the cargo being shipped. The unit is stowed on blocks and beams during terminal storage and onboard the vessel. Cargo types include: transformers, generators, boilers, rotors, tunnel boring machines and hydraulic press machines.

Equipment details

< 140 MT per set

Cargo max weight

6-40 m

Cargo max length

Turnable 3x2 m

Equipment length

Turnable 3x2 m

Equipment width

0.94-1.1 m

Equipment height

Multi-Purpose Bogie (MPB)

The Multi-Purpose Bogie (MPB) is our latest invention. They are used in pairs and are suitable for long cargo up to 140 tonnes. The MPB can be fitted with different kind of attachments depending on the cargo. For instance, railed beams for trains and locomotives or a 22 m transport platform to create a roll trailer which can be maneuvered from both ends. The turntables, of the MPBS, can also be connected together to create a short, light version of our Samson trailers. The Samson light is suitable for generators and transformers.

Equipment details

< 23 MT

Cargo max weight

9 m

Cargo max length

< 3.5 m

Cargo max width

6.10 m

Equipment length

2.44 m

Equipment width

0.23 m

Equipment height

Bolster

Designed for smaller breakbulk cargo which is not suited for direct stowage on a vessel deck. Bolsters are suitable to minimise the handling operation in the port as several small pieces of cargo can be loaded on a bolster and forklifted onboard. Cargo types include: steel plates and coils, small yachts, crates and machinery.

Global trade network

Our trade maps provide a great overview of WW Ocean's global liner services. The detailed maps specify ports of load and ports of discharge, transit time and frequency as well as other practical info.

See our trade maps
